Description

SKU MO6743S

MO-6743S

ALL-IN-ONE 3-NEEDLE, 6-THREAD OVERLOCK WITH SAFETY STITCH

All overlock/serger operations in one machine:

♥ 3-Thread Stitch

♥ 4-Thread Stitch

♥ 4-Thread with Safety Stitch

♥ 5-Thread with Safety Stitch

Condition	New
Application	Medium to heavy-weight
Max. sewing speed	7,000 sti/min*
Needle bar stroke	24.5 mm
Needle system (at time of delivery)	DCx27 (81x1) #10~#18
Lubricating oil	JUKI Machine Oil 18 (equip. ISO VG18)
Stitch type	Safety stitching
Stitch style in the U.S.A.	516
Needle gauge (mm)	4.8 mm + 2.0 mm
Diff-feed adj. method	By lever (w micro-adjustment)
Weight of machine head	28 kg
Overedging width (mm)	3.2 mm
Differential feed ratio	Gathering 1:2 (max 1:4) Stretching 1:0.7 (max 1:1.6)
Inclination angle of the needle	20º
Needle mechanism	Ndl bar method & upper/lower bushing
