Description

SKU GA1398-1

GA1398-1

HIGHLEAD EXTRA LARGE, LONG-BEAK  OSCILLATING SHUTTLE HOOK AND BOBBIN EXTRA HIGH FT LIFT – (1¼”)  TWO ROW FEEDER W/REVERSE

This extra heavy duty top and bottom feed lockstitch machine comes with a high arm clearance and extra wide bed to make it easy to sew large articles. The large machine pulley helps the machine to attain strong striking power – thus making sewing on multi-layer extra heavy material, whether slippery or gummy simple. The cam thread take up and large shuttle hook with large bobbin capacity mean less down time for bobbin changes. Its extra high foot lift and long needle bar stroke make it the ideal machine in the manufacture of safety belts, webbing, leather trunks, buffing wheels, tents, sails, car covers, book bindings, and similar articles.

Recommended for:

♥ Safety Belts

♥ Heavy Webbing

♥ Leather Trunks

♥ Buffing Wheels

♥ Tents

♥ Sails

♥ Car Covers

♥ Book Bindings

♥ & much more!!!

• Condition:New
• Application:Heavy-weight materials
• Max. sewing speed:700 rpm/spm
• Max. stitch length:0-15mm
• Needle bar stroke:66mm
• Lift of presser foot by hand:29mm
• Lift of presser foot by knee:32mm
• Needle system (at time of delivery):SM x 1000 Nm250/27
• Lubrication:Manual
• COMPLETE SET-UP:TABLE, STAND & CLUTCH MOTOR
• Shop warranty:Houston, TX area: 90-days service warranty & 1-year on motor
